This 4-Bedroom Duplex is a one-storey building with a suspended floor, designed to balance luxury, functionality, and family comfort. Every bedroom is ensuite, providing privacy and convenience for residents. The duplex features generous living spaces, open family lounges, sit-outs/balconies, and void spaces for elegance and modern architectural appeal.
Ground Floor Features
✅ Bedroom 1 (Ensuite):
4.20m × 4.20m (13.78ft × 13.78ft) — spacious and functional, ideal as a guest or family bedroom.
✅ Bedroom 2 (Ensuite, accessed via Ante Room):
4.20m × 3.60m (13.78ft × 11.81ft) — suitable as a private guest room.
✅ Kitchen:
5.70m × 4.00m (18.70ft × 13.12ft) — fully functional, with a store for organized storage.
✅ Store:
1.80m × 1.80m (5.91ft × 5.91ft) — for pantry or additional kitchen storage.
✅ Laundry Room:
3.00m × 2.00m (9.84ft × 6.56ft) — connected to the back sit-out for outdoor utility.
✅ Living Room/Lounge:
7.30m × 4.80m (23.95ft × 15.75ft) — spacious and airy, perfect for family gatherings.
✅ Dining Area:
4.80m × 2.50m (15.75ft × 8.20ft) — seamlessly connected to the lounge for ease of service.
✅ Ante Room with Visitor’s Toilet/Convenience:
5.40m × 3.30m (17.72ft × 10.83ft) — welcoming entry and guest convenience.
✅ Back Sit-Out:
Accessible from the kitchen and laundry, providing ventilation and outdoor functionality.
✅ Staircase:
One main staircase connecting the ground floor to the first suspended floor.
First Suspended Floor Features
✅ Bedroom 3 (Ensuite):
5.70m × 5.70m (18.70ft × 18.70ft) — ensuite with walk-in closet, spacious bathroom, and private sit-out.
✅ Master Bedroom (Ensuite):
7.00m × 4.20m (22.97ft × 13.78ft) — luxurious master suite with walk-in closet, generous bathroom/convenience, and private sit-out.
✅ Family Lounge:
5.40m × 3.30m (17.72ft × 10.83ft) — connected to the front sit-out/balcony and overlooks a void to the ground floor living area, enhancing openness and light.
✅ Staircase:
One staircase connecting to the ground floor, ensuring smooth movement between levels.
Available Drawings:
Complete set of building plans available for:
✅ Architectural
✅ Structural (with calculation sheets)
✅ Electrical
✅ Mechanical
You can get:
✅ Softcopies (PDF) sent to your email
✅ Hardcopies printed in four sets and delivered to your location
Click on "Buy Now" below to get this plan and start building today!
